Fused Imaging Fiber Optics
All SCHOTT Fiber Optic Faceplates are fabricated to customer-specific requirements. Typical shapes are round or rectangular, and available in a range of sizes up to 320 mm2 formats.
Fiber sizes range from 2.5 µm and up. The faceplaces can be manufactured to be vacuum tight.
SCHOTT Fiber Optic Inverters are manufactured using fiber elements ranging in size from 4 to 25 µm that are fused together into a coherent imaging array, which is then heated and twisted to invert the image 180o from the input surface to the output surface.
All SCHOTT Tapers are fabricated to customer-specific requirements and can be machined into configurations from round to round, square to square, round to square or rectangular. Formats up to 75 mm in diameter and magnification ratios up to 3:1 are all available.
Our tapers can also be bonded together in arrays of linear, square or rectangular shapes, while we can also bond our fiber optics to a range of sensors. All tapers are compatible with the common optical coating capabilities of AR, Hot Mirror and ITO.
To find out more information about the range of options and services available for SCHOTT Bonded Assemblies, please get in touch with us.
