ColdVision Fiber Optic Light Guides

The technical properties of SCHOTT Light Guides and their range of light sources and accessories enable the precise camera systems in machine vision equipment to achieve optimum performance. Since consistency is key for decision-making, our light guides have built-in accuracy and reliability.

Trusted around the world since 1970

Mechanically stable

Despite their light weight, SCHOTT Light Guides offer strong protection against pressure and other mechanical challenges for improved fiber longevity. The extensive range of bundles also exhibit extremely small bending radii, as well as high flexibility.

Heat-free illumination

SCHOTT launched its first cold light source and light guides in 1970. Constantly driving innovation, SCHOTT has established the ColdVision series as a trusted brand for companies and organizations worldwide. As the light is guided from the source by our light guides, heat at the object is kept to a minimum.

Modular system with a broad portfolio

SCHOTT Light Guides are part of a series of modular ColdVision products that are highly compatible and easy to combine. These products include a number of light guide formats, as well as five different light sources that provide an array of combinations that cover most demanding applications.

Every accessory you need

Alongside our light guides and light sources, the SCHOTT ColdVision family includes a wide variety of mechanical and optical accessories. This further increases the flexibility of the series and provides customizable illumination for the vast majority of machine vision and microscopy requirements.
Gooseneck Light Guides

Single and Dual Goosenecks

Table showing the technical specifications of single and dual Goosenecks  for ColdVision Fiber Optic Light Guides



Combination Goosenecks and Bundles

Table showing the the technical specifications of goosenecks and bundles combination for ColdVision Fiber Optic Light Guides

* Made-to-order products
Custom configurations available. Compatible accessories available. See ColdVision Accessories Datasheet.

Flexible bundles

Table showing the the technical specifications of flexible bundles for ColdVision Fiber Optic Light Guides

* Made-to-order products
Custom configurations available. Compatible accessories available. See ColdVision Accessories Datasheet.


Ring Lights

Mini, midi and maxi Ring Light

Table showing the technical specifications of mini, midi and maxi Ring Lights for ColdVision Fiber Optic Light Guides



66mm and universal Ring Light

Table showing the technical specifications of 66m and universal Ring Lights



Darkfield Ring Light

Table showing the technical specifications of Darkfield Ring Lights for ColdVision Fiber Optic Light Guides

* Made-to-order products
1 29% more fiber than A08650 ring light
2 Randomized fiber bundle maximizes uniformity
3 Requires an adapter (A08931) due to the size of the input
4 Remove the reflector ring to create a long working distance    Ring Light (A08700).
5 If using the A08626 adapter, use A08627 polarizer/analyzer.
Custom configurations available. Compatible accessories available. See ColdVision Accessories Datasheet.


Back Lights

Single and dual back lights

Table showing the technical specifications of single and dual Back Lights for ColdVision Fiber Optic Light Guides

* Made-to-order products
1 Uniformity scans are available upon request
Custom configurations available. Compatible accessories available. See ColdVision Accessories Datasheet.


Line Lights

Table showing technical specifications of Line Lights for ColdVision Fiber Optic Light Guides

* Made-to-order products
1 Gamma setting of 1.0.  Dimensions in ( ) are in mm
Custom configurations available. Compatible accessories available. See ColdVision Accessories Datasheet.







Accessories

Bundle accessories – mechanical

Table showing the technical specifications of mechanical bundle accessories for ColdVision Fiber Optic Light Guides

* Made to order product
Using a bundle extender results in a 30-40% light loss



Bundle accessories – optical

Table showing the technical specifications of optical bundle accessories for ColdVision Fiber Optic Light Guides



Ring Light accessories

Table showing the technical specifications of Ring Light accessories for ColdVision Fiber Optic Light Guides



Line Light accessories

Table showing the technical specifications of Line Light accessories for ColdVision Fiber Optic Light Guides

* Made to order product
