Pump Laser Modules
TO method of production giving rise to economical benefits.
About
Pump laser modules are suitable for use in 980nm or 1480nm pump lasers for long haul, CATV or Gas Sensors.Product features
- Ferrule or window option, brazed or welded.
- Selective Plating technology to reduce gold and provide stability in the face of fluctuating gold prices.
- Superior thermal performance with Copper baseplate and steel body combination.
- Best way to bring the cost down.
- Gold plated pins for wire bonding.
- Heatsink with screw holes for mechanical attachment to PCB.
- Ample Space for subassemblies in package.
Product images
Pump laser module
Butterfly package for pump laser
Simulation Assumptions:
Heat Source: TEC (A=7.5x3.5mm, H=1mm)
Power of LD: 1W
Heat Sink: Size of package, T=constant 20°C
