High Refractive Index Ball Lens Caps
AboutThe Transistor outline caps fulfill two primary functions. First, they protect the optical components of transmission as well as reception applications. Second, they ensure the transmission of the optical signals by acting as an optical interface.
SCHOTT High Refractive Index Ball Lens Caps are low-cost alternative for Aspherical lens in PON market for Laser Packaging.
- Available in diameters from 0.8 – 2.0mm.
- Various high refractive index lens material to choose from.
- Turned metal caps available in SF20T, SF20F, and other stainless steel versions.
- Coupling Efficiency up to 30%.
- Beneficial for Rx with small spot size, 20µm.
- Many options to complement headers.
|Lens material||LaSF H17||K-VC89||N-LaSF 44|
