LED Fiber Lighting Modules

The technical qualities of the SCHOTT® LED Fiber Lighting Module (FLM 4) generate spot-on illumination, with the versatility to tackle a wide range of medical applications. Specific benefits enable innovative designs, applications and functionalities with precision and durability, as well as customization options.

Precise properties for the medical professional

Surgery-ready color rendering

The FLM 4 is the ideal option for smaller light guides used in surgery, diagnostics and many other medical applications. Assisted by an optimized optical focusing system, it generates color temperature from 2700-5700K, with a typical CRI score of 70-90.

Easily adjustable

Powered by constant current, the FLM 4 is highly adjustable – the light intensity of its LEDs can be continuously dimmed between 0% and 100%, yet remains flicker-free.

Cool under pressure

Performance and endurance are must-haves for essential medical equipment, and the FLM 4 features an integrated fan to ensure optimum cooling during operation, which also helps to extend service life.

Excellent for ENT

With the FLM 4’s external triggering option, fast body action can be made highly visible under the spotlight of the LED. This is extremely useful in ear, nose and throat procedures where surgeons need to see the vocal chords moving.

Customization

Customization

Optical Data

LED Fiber Lighting Type SCHOTT® FLM 4 2A SCHOTT® FLM 4 4.5A
LED Type White High Brightness LED White High Brightness LED
Color Temperature CCT 5700 Kelvin (initial value) 5700 Kelvin (initial value)
Color Rendering Index CRI Approx. 70 Approx. 70
Typical Luminous Flux 900lm in Focal Area 400 lm out of SCHOTT® light guide (GOF 70, 4.8 mm, 2300 mm) 2000lm in Focal Area 750 lm out of SCHOTT® light guide (GOF 70, 4.8 mm, 2300 mm)
Aperture angle 65°in 5 mm focal diameter 65°in 5 mm focal diameter
Average LED Lifetime 30,000 hours (Luminous Flux reduced to 70% of Maximum) 30,000 hours (Luminous Flux reduced to 70% of Maximum)
Please note LEDs are subject to certain manufacturing variations and can change their intensity and chromaticity depending on the type, power rate, life time and environmental conditions. LEDs are subject to certain manufacturing variations and can change their intensity and chromaticity depending on the type, power rate, life time and environmental conditions.



Graph showing the spectrum of the SCHOTT® FLM 4, measured with SCHOTT® light guide



Electronic Data / PCB

LED Fiber Lighting Type SCHOTT® FLM 4 2A SCHOTT® FLM 4 4.5A
Operating Voltage / Current 12 V DC +2V/-1V DC, 2 A max. 12 V DC +2V/-1V DC, 6.5A max.
LED Safety/redundancy Serial chain Serial chain
Power Consumption 72 watt max 72 watt max
Analog Input Voltage 0 - 5 V 0 - 5 V
Range for Dimming 0 - 100 %  0 - 100 %
Applicable Potentiometer for Dimming 10 KΩ 10 KΩ
Method of LED Dimming Only for analog dimming: Linear Current Control 0-4000 mA / LED Only for analog dimming: Linear Current Control 0-4000 mA / LED
External Trigger Input 5 Hz – 1.2 KHz, var. pulse/pause ratio 5 Hz – 1.2 KHz, var. pulse/pause ratio
Interface/PCB 10-pin terminal connector socket for dimming, overheating  protection, external trigger signal, 2-pin connector socket for power supply 10-pin terminal connector socket for dimming, overheating  protection, external trigger signal, 2-pin connector socket for power supply

Dimensions

LED Fiber Lighting Type SCHOTT® FLM 4 2A SCHOTT® FLM 4 4.5A
Optics Module / Fan Diameter 45 mm / 50mm  x 50 mm, Length 70 mm Diameter 45 mm / 62mm  x 62 mm, Length 98 mm
Focal Distance 16 mm from front plane of metal housing 16 mm from front plane of metal housing
Weight Approximately 230 g  Approximately 250 g
PCB dimension (L x W) 100 mm x 60 mm 100 mm x 60 mm



Operating Conditions

LED Fiber Lighting Type SCHOTT® FLM 4 2A SCHOTT® FLM 4 4.5A
Ambient Temperature + 5 - + 35°C + 5 - + 35°C
Relative Humidity 85% max. (non-condensing) 85% max. (non-condensing)


Transportation and Storage

LED Fiber Lighting Type SCHOTT® FLM 4 2A SCHOTT® FLM 4 4.5A
Temperature - 20°C - + 70°C - 20°C - + 70°C
Relative Humidity 10 … 95% (non-condensing) 10 … 95% (non-condensing)
