Fused Imaging Fiber Optics

SCHOTT Fused Imaging Fiber Optics transmit a high quality image with minimal distortion and transmission loss. We transform our customers’ vision into customized forms, shapes, lengths and diameters of fused fiber optics. These are developed for specific applications and environments.
Fiber optic image inverter showing inverted image of word SCHOTT

High quality form and performance

Our range of high quality fiber optic materials and processing provides a wide spectrum of forms and shapes to suit individual customer needs. Whether you require faceplates, tapers, inverters or bonding solutions, we can customize our products to your exact requirements.

Range of SCHOTT Fiber Optic Faceplates

High resolution imaging

Fiber size as low as 2.5 µm provides high quality image transfer and resolution. Combined with traditional optical or scintillating coatings, our optics provide a wide range of solutions from image intensification to x-ray imaging for a variety of applications.

Range of SCHOTT Fused Imaging Fiber Optics

Product variants

SCHOTT Fused Imaging Fiber Optics can be designed to magnify, minify, invert or simply transfer an original image to anywhere needed for defense, medical, and industrial applications.

MORE ABOUT VARIANTS
Faceplates Gruppe
Fiber optic image inverter showing inverted image of word SCHOTT
Fused Imaging Fiber Optic Straight Thru
Four clear SCHOTT Image Conduits of different sizes
Range of fiber optic tapers of different shapes and sizes
