KL Fiber Optic Light Guides

The physical properties of SCHOTT’s Fiber Optic Light Guides offer a number of benefits for the professional user, including strong mechanical protection and high compatibility with a range of lighting products and accessories. This results in a complete lighting system that delivers consistent performance.

Light guides for modular, flexible microscopy

Mechanical stability

Our light guide designs are lightweight yet offer strong protection against pressure and other mechanical challenges for improved fiber longevity. The bundles also have extremely small bending radii, as well as high flexural capabilities.

Reduced heat influx

SCHOTT launched its first cold light source in 1960, and these sources were quickly established as a market standard. As the light is guided from the cold light source via light guides, heat at the specimen is reduced to a minimum.

Modular system with broad portfolio

SCHOTT KL Light Sources and Light Guides are highly compatible. A choice of different light guide variants makes all common illumination techniques possible.

Accessories

SCHOTT light guides are available with a broad range of mechanical and optical accessories to further enhance the system’s flexibility.

Goosenecks

Table showing the technical specifications of SCHOTT Gooseneck Light Guides

Flexible Light Guides

Table showing the technical specifications of SCHOTT Flexible Light Guides

Ring Lights

Table showing the technical specifications of SCHOTT Ring Lights

Line Lights

Table showing the technical specifications of SCHOTT Line Lights

Accessories

Mechanical Accessories

Table showing the mechanical accessories of SCHOTT KL Fiber Optic Light Guides



Optical Accessories

Table showing the optical accessories of SCHOTT KL Fiber Optic Light Guides

System diagrams

Light Guides for KL 300 LED

A wide range of SCHOTT KL Light Guides and Accessories are compatible with the SCHOTT KL 300 LED Light Source. Please examine the system diagram below for more information.

System diagram showing the compatibility of SCHOTT KL Light Guides and Accessories with the SCHOTT KL 300 LED Light Source



Light Guides for KL 1600 LED / KL 2500 LED / KL 1500 HAL

A wide range of SCHOTT KL Light Guides and Accessories are fully compatible with the SCHOTT KL 1600 LED, KL 2500 LED and KL 1500 HAL Light Sources. Please examine the system diagram below for more information.

System diagram of the SCHOTT KL 1600 LED, KL 2500 LED and KL 1500 HAL Light Sources
