Square Transistor Outline Caps

Giving our Caps and Lids an edge.

Registration Necessary

To see this content you have to register.

*Field is required

Společnost SCHOTT použije vaše údaje pouze k reakci na váš dotaz. Další informace o zpracování vašich osobních údajů.

About


In opto-electronics, the transistor outline caps/lids fulfill two primary functions. First, they protect the optical components of transmission as well as reception applications. Second, they ensure the transmission of the optical signals by acting as an optical interface.

Rectangular caps and lids are used for opto-electronic applications (Sensors, LED packages etc.)

Product features

  • Fits to rectangular glass-to-metal and ceramic packages.
  • Deep drawn metal can for direct soldering onto ceramic packages.
  • Available with lens or flat window designs, round or rectangular shaped windows.
  • Glass with UV transmission is available.
  • Reliable hermeticity.
  • High thermal and mechanical stability.
  • Some of the design patent is granted.

Product images

Square Transistor Outline Cap

Square Transistor Outline Cap

Customized window designs

Graphic visualizing customized window designs
